BEQUIET! DARK POWER PRO 13 1300W POWER SUPPLY

Apraksts

Technical details Sustainability: Yes Design Product color: Black Number of fans: 1 fan Fan bowl diameter: 13.5 cm Cooling type: Active Power Total power (+5V): 150 W Total power (-12V): 6 W Maximum output current (+5 Vsb): 3.5 A Total power (+12V): 1300 W Maximum output current (+12 V3): 40 A Power factor: 0.99 AC input frequency: 50 - 60 Hz Maximum output current (+12 V1): 35 A Total power (+5 Vsb): 17.5 W Efficiency: 94.5% Maximum output current (+12 V4): 40 A Maximum output current (-12V): 0.5A AC input voltage: 115 - 240 V Input current: 15 - 9 A Total power: 1300 W Maximum output current (+3.3V): 25 A Maximum output current (+5V): 25A Power protection features Overload protection Short circuit Overheating protection Protection against overvoltage Overcurrent Low voltage protection Hold time: 18 ms Peak power: 1400 W Maximum output current (+12 V2): 35 A Total power (+3.3V): 150 W Weight and dimensions Product width: 150 mm Product weight: 2.41 kg Product depth: 200 mm Product height: 86 mm Efficiency Intended use: PC 80 PLUS Certified: 80 PLUS Titanium Bearing Technology: FDB ATX version: 3.0 Power supply type (PSU): ATX MTBF (Mean Time Between Failures): 100000 h EPS version: 2.92 Noise level: 23.2 dB Packaging data Package depth: 417 mm Package height: 152 mm Package width: 253 mm Weight with packaging: 6.8 kg Package contents Cables: Processor, PCIe, Peripheral (Molex), SATA Cable clamps included: Yes Certificates Certificates of conformity Federal Communications Commission (FCC) CCC UKCA CE Ports and interfaces PCI Express power cable length: 60 cm Wiring Type: Fully Modular CPU power cable length: 70 cm Peripheral (Molex) Power Cable Length 900 mm 600 1050 mm 750 PCI Express slot: Yes ATX power supply connector (20+4 pin): Yes PCI Express power connectors (6+2 pin): 6 Number of SATA power connectors: 16 Number of PATA power connectors: 5 SATA power cable length 500 mm 1050 mm 950 mm 800 mm 750 mm 600 900 mm Motherboard cable length: 60 cm Motherboard power connector: 20+4 pin ATX EPS power supply connector (8-pin): Yes EPS power connector (4+4 pin): Yes Logistics data Delivery box width: 32.5 cm Delivery box height: 28.3 cm Shipping box length: 44 cm Products per shipping crate (inner): 2 pcs. Warranty period: 10 years Net weight of the delivery box: 14.4 kg Safety warning Warnings Do not open the housing – risk of electric shock. Avoid contact of the product with water or other liquids. The product is not suitable for disposal with municipal waste – dispose of in accordance with local regulations.

Category

Computers and accessories

Department

Electronics

Weight (kg)

6.6

Product Type

Power supplies
