QuWireless AX50MO antenna – omnidirectional PoE/LAN antenna, 4 dBi

Apraksts

Features Antenna connector type: PoE/LAN Antenna type: Omnidirectional antenna Mounting type: Wall/Pole IP protection rating: IP67 Housing material: Acrylonitrile butadiene styrene copolymer (ABS) Product colour: White Intended use: Indoor / outdoor Polarisation: Vertical polarisation Waterproof: Yes Voltage standing wave ratio (VSWR): 2 Power Power supply type: PoE Weight and dimensions Product height: 486 mm Product depth: 105,6 mm Product width: 292,2 mm Product weight: 2,5 kg Operating conditions Operating temperature range: -40 - 70 °C Performance Frequency band: 0.617-0.96/1.7-2.2/2.2-2.7/3.3–3.8; 2.4-2.5/4.7-6 Maximum antenna gain level: 4 dBi Horizontal beamwidth: 360° Horizontal beamwidth (2.4 GHz): 360° Vertical beamwidth (5 GHz): 25° Antenna range (2.4 GHz): 6 dBi Vertical beamwidth (2,4 GHz): 25° Gain factor: 3 / 4 dBi Impedance: 50 Ω Vertical beamwidth: 35° Horizontal beamwidth (5 GHz): 360° Antenna range (5 GHz): 7 dBi Package contents Quantity: 1 User manual: Yes Logistics data Country of origin: Poland

Category

Networking & Communication, Computers and accessories

Department

Electronics

Weight (kg)

1.8
